WONVAC WVS, WBS DRY PUMP_SINGLE TYPE
가로 스크롤 밀어서 전체 내용 보실 수 있습니다.
| Model | Pumping Speed (60HZ / 50Hz) |
Kw | Ultimate Pressure |
Data sheet | Manual | |
|---|---|---|---|---|---|---|
|
|
WVS-3 / 3H | 280 / 235 L/min | 0.4kw | 3 - 450mmHg 3H - 600mmHg |
 |
|
|
|
WVS-5 / 5H | 480 / 405 L/min | 0.75kw | 5 - 450mmHg 5H - 600mmHg |
|
|
|
|
WVS-6 / 6H | 685 / 575 L/min | 1.5kw (4P) | 6 - 450mmHg 6H - 600mmHg |
|
|
   |
WVS-8 / 8H | 1115 / 935 L/min | 1.5kw (6P) | 8 - 450mmHg 8H - 600mmHg |
|
|
|
|
WVS-9 / 9H | 1350 / 1130 L/min | 2.2kw (6P) | 9 - 450mmHg 9H - 600mmHg |
|
|
   |
WVS-10 / 10H | 2200 L/min | 4kw | 10 - 410mmHg 10H - 600mmHg |
|
|
|
|
WVS-10A / 10AH | 2350 / 1960 L/min | 4kw | 10A - 410mmHg 10AH - 600mmHg |
|
|
 |
WVH-2 | 145 / 120 L/min | 0.2kw | 400~720mmHg | |
|
|
|
WVH-3 | 260 / 220 L/min | 0.4kw | 400~720mmHg | |
|
|
WVH-5 | 400 / 330 L/min | 0.75kw | 400~720mmHg | |
|
